ATRO CR00-67661 Self Aligning Carrier Bearing Replaces Spicer 10094142

ATRO CR00-67661 is a self-aligning polyurethane carrier (center support) bearing for the 1810-Series Spicer driveshaft family, replacing Spicer 10094142 and the 210661-1X service-bearing pattern shared across most heavy-duty driveshaft brands. The patented ATRO design provides ±10° of pivot, eliminating the need to shim during installation. The polyurethane sleeve absorbs vibration and resists chemical attack from oil, grease, fuel, and road salt; the housing is built from 7-gauge steel.

Signs You Need a New Carrier Bearing

• Driveline vibration or rumble at highway speed
• Squealing or grinding from the center of the driveshaft
• Visible cracking, separation, or sag of the bearing rubber/polyurethane sleeve
• Driveshaft droop, runout, or visible play at the carrier

Specifications

Cross References

This part replaces or is equivalent to the following 1810-Series carrier bearing part numbers:

• Dana Spicer: 10094142, 210661-1X, 2106611X, 5003323
• Timken: HB88512A, HB88512AHD, 210661-1XSA
• Meritor: 210661-1X
• Paccar: CB210661-1XSA
• Kenworth: 210661-1X, CB2106611XSA
• Peterbilt: 210661-1X, CB2106611XSA
• Mack: 210661-1X
• International: 283071C93, CB2106611XSA
• Volvo: 85110609, 85110611, 3093623, 210661-1X
• Freightliner: SP2106611X
• Autocar: 210661-1X
• Ford: D4TZ4800J
• GMC / Chevrolet: 15512196
• Also known as: Mack 203SJ13; Gaff 40197, 40074; TBR2106611XSA

Applications

This carrier bearing fits any driveshaft that uses the 1810-Series 60 mm-bore service bearing pattern, including:

• Spicer 817099-XXX driveshaft family (1810 Series)
• Paccar, Kenworth, Peterbilt, Freightliner, International, Volvo, Mack, Autocar, Ford, and GM driveshafts using the 210661-1X / Timken HB88512A pattern

Verify driveshaft series, bearing bore, and bolt-hole spacing on your truck before ordering. The 1810 Series and 60 mm bore must both match — other Spicer series (1710, 1760, 1480) use different carrier bearings.
