The Bosch 69909 is the genuine OEM electric fuel lift pump for 1998-2003 Ford Super Duty trucks and vans equipped with the 7.3L Power Stroke diesel engine. Bosch is the original equipment manufacturer of this pump, and part number 69909 is the exact replacement for the frame-rail mounted fuel supply pump located on the driver's side. This roller-vane pump draws fuel from the tank and delivers it under pressure to the fuel bowl and HEUI injection system, providing the consistent fuel supply critical to Power Stroke performance and longevity.
Signs You Need a New Fuel Pump
- Hard starting, extended cranking, or no-start condition
- Loss of power under load, especially when towing or climbing hills
- Engine stalling, surging, or hesitation during acceleration
- Loud whining, buzzing, or grinding noise from the fuel pump area
Specifications
| Manufacturer | Bosch |
|---|---|
| Part Number | 69909 |
| Part Type | Electric Fuel Lift Pump |
| Engine Compatibility | Ford 7.3L Power Stroke Diesel |
| Model Years | 1998-2003 |
| Flow Rate | 40-49.5 GPH |
| Pressure Range | 72.5-116 PSI |
| Voltage | 12V |
| Inlet/Outlet Size | 5/16" |
| Mounting Hardware | Included |
Cross References
This part replaces or is equivalent to the following part numbers:
- Ford: F81Z9C407AC, F81Z-9C407-AC, F8149350AA, F814-9350-AA
- Bosch: 0580464074, 0 580 464 074, 69136
- Airtex: E2236
- Carter: P74221
- Delphi: HFP920
- Standard Motor: E1541101
Applications
This fuel pump fits 7.3L Power Stroke diesel engines found in:
- 1999-2003 Ford F-250 Super Duty
- 1999-2003 Ford F-350 Super Duty
- 1999-2003 Ford F-450 Super Duty
- 1999-2003 Ford F-550 Super Duty
- 2000-2003 Ford Excursion
- 1999-2003 Ford E-350/E-450/E-550 Econoline Super Duty
Installation Notes
- Located on the driver's side frame rail between the fuel tank and engine
- Transfer mounting bracket, isolator pad, outlet fitting, and wiring pigtail from old pump
- Replace fuel filter when installing new pump
- Inspect fuel lines for cracks, kinks, or collapsed sections
Note: This pump fits 1999-2003 Super Duty models with frame-rail mounted electric pump. Earlier 1994-1997 7.3L Power Stroke trucks use a mechanical cam-driven lift pump. Verify your application before ordering.
