Caterpillar 1946724 Oil Pressure Sensor

PAI 350595 engine oil pressure sensor replacing Caterpillar 194-6724 (and predecessors 161-9929, 143-9694, 129-8374) on Cat 3100 Series and C7 on-highway truck engines. Triangular 3-pin connector with 7/16-20 thread; supplies oil pressure data to the ECM for low-pressure protection and gauge readings.

Signs You Need a New Oil Pressure Sensor

• Erratic, pegged, or no reading on the oil pressure gauge
• Active low-oil-pressure warning with confirmed normal pressure at the test port
• Diagnostic codes for oil pressure circuit (e.g., SPN 100 / FMI 3, 4, or 8)
• Engine derate or shutdown triggered by false low-pressure signal

Specifications

Cross References

This part replaces or is equivalent to the following part numbers:

• Caterpillar: 194-6724 / 1946724, 161-9929 / 1619929, 143-9694 / 1439694, 129-8374 / 1298374

Applications

This oil pressure sensor fits the following engines:

• Caterpillar 3116 (1988-1997)
• Caterpillar 3126 / 3126B / 3126E (1997-2004)
• Caterpillar C7 on-highway (2004-2010)

Representative vehicles and equipment using these engines:

• Class 6/7 medium-duty trucks with Cat 3126/3126B/3126E or C7 (Freightliner M2 106, International 4300, Sterling Acterra, Kenworth T300, Peterbilt 330)
• School bus and shuttle chassis with C7 (1996-2010)

Verify your engine serial number and configuration before ordering to confirm fitment. Do not extend to C9, C11, C13, or C15 without verification.
