HD Value HDV8729 Air Spring⎪Replaces Firestone W01-358-8729 ^Sale

Model/Style: Rolling Lobe
Bottom Plate Alignment: Parallel
Bottom Plate Center to Center Diameter: 2.25 (Inch)
Bottom Plate Diameter: 10.05 (Inch)
Bottom Plate Hole Quantity: 1
Bottom Plate Type: A
Design Height: 7 (Inch)
Load Rating at 100 PSI: 9900 (Pound)
Load Rating at 80 PSI: 7800 (Pound)
Maximum Diameter: 13.7 (Inch)
Maximum Height: 14.4 (Inch)
Minimum Height: 4.7 (Inch)
Natural Frequency: 103
Spring Type: Rolling Lobe
Top Plate Center to Center Diameter: 5.5 (Inch)
Top Plate Diameter: 10.2 (Inch)
Top Plate Hole Quantity: 2

Cross Reference:

• Automann:  AB1DK25D-8729
• Batco: 10-98729
• Continental-ContiTech: 10 10B-13 S 513
• Continental-ContiTech: 1010B13S513
• Continental-ContiTech: 75741
• ContiTech: AS8729
• Dayton Parts: 352-8729
• Euclid: E-FS8729
• Firestone: 8729
• Firestone: W01-358-8729
• Goodyear: 1R13-130
• HDValue: HDV8729
• Meritor: A2258F1410
• Meritor: FS8729
• Triangle Air Springs: 8513
• Triangle Air Springs: AS-8513
